3/8 Jic 37° Male Flare x 1/4 Npt Female Steel Hydraulic 3 Way Branch Tee

2602-06-06-04

Dash Size: -6 Tube OD: 3/8" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 9/16" x 18 Tpi)

Npt Thread: 1/4" Npt x 18 Tpi Female (Actual Nominal Thread Size 1/2")

JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel
