3/4 Jic 37° Male Flare Bulkhead 45 Degree Elbow Hydraulic Steel Fitting 2702-12-12

3/4 Jic 37° Male Flare Bulkhead 45 Degree Elbow Hydraulic Steel Fitting 2702-12-12

Dash Size: -12 Tube OD: 3/4" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 1-1/6" x 12 Tpi)Overall Length: 4.21"

Overall Length: 3"

Max Panel Depth: 0.5"

Hole Diameter: 1.05"

Wrench Size for Nut: 1.37"

JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel
