FasParts
2 Jic 37° Flare Male x 2 Npt Male 45 Degree Elbow Hydraulic Steel Fitting FasParts 2503-32-32
2 Jic 37° Flare Male x 2 Npt Male 45 Degree Elbow Hydraulic Steel Fitting FasParts 2503-32-32
Regular price
$126.00 USD
Regular price
Sale price
$126.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
2503-32-32
Dash Size: -32 Tube OD: 2" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 2-1/2"-12 Tpi)
Npt Thread: 2" Npt Male
2 Jic 37° Flare Male x 2 Npt Male 45 Degree Elbow Hydraulic Steel Fitting FasParts 2503-32-32
JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel
