FasParts
1 Jic 37° Flare Male x 1 1/4 Male Npt Straight Hydraulic Fitting Adapter Steel FasParts 2404-16-20
1 Jic 37° Flare Male x 1 1/4 Male Npt Straight Hydraulic Fitting Adapter Steel FasParts 2404-16-20
Regular price
$17.08 USD
Regular price
Sale price
$17.08 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
2404-16-20
Dash Size: -16 Tube OD: 1" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 1-5/16" x 12 Tpi)
Npt Thread: 1-1/4" Npt Male
1 Jic 37° Flare Male x 1 1/4 Male Npt Straight Hydraulic Fitting Adapter Steel FasParts 2404-16-20
JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel
