1/4 Jic 37° Male Flare Bulkhead 90 Degree L Elbow Hydraulic Fitting 2701-04-04

1/4 Jic 37° Male Flare Bulkhead 90 Degree L Elbow Hydraulic Steel Fitting 2701-04-04

Dash Size: -4 Tube OD: 1/4" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 7/16" x 20 Tpi)

Overall Length: 2"

Max Panel Depth: 0.35"

Hole Dia: 0.45"

Wrench: 0.7"

JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel

(Please See photo 2 for sizing guide)
