1 1/2 Jic 37° Flare Male x 1 1/2 Npt Male 45 Degree Elbow Hydraulic Steel Fitting FasParts 2503-24-24

2503-24-24

Dash Size: -24 Tube OD: 1-1/2" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 1-7/8" x 12 Tpi)

Npt Thread: 1-1/2" Npt Male

1 1/2 Jic 37° Flare Male x 1 1/2 Npt Male 45 Degree Elbow Hydraulic Steel Fitting FasParts 2503-24-24

JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel
