1 1/2 Female Jic 37° x 1 1/4 Male Jic 37° FasParts Hydraulic Steel Reducer Adapter

2406-24-20

Dash Size: -24 Tube OD: 1-1/2" Jic 37 / Sae 37 Female (Actual Nominal Thread Size 1-7/8" x 12 Tpi)

Dash Size: -20 Tube OD: 1-1/4" Jic 37 / Sae 37 Male (Actual Nominal Thread Size 1-5/8" x 12 Tpi)

1 1/2 Female Jic 37° x 1 1/4 Male Jic 37° FasParts Hydraulic Steel Reducer Adapter

JIC (Joint Industrial Council) fittings, provide a tight metal to metal seal on tubing that is flared to 37° degrees. Fittings require a nut and a sleeve (ferrule) for each tube end. Nuts and sleeves are sold separately.
Suitable for: Air, Hydraulic Fluid, ATV, Isopropyl Alcohol, Natural Gas, Fuel, Lubricants, Fresh Water
Working Temperature: -65°F (-54°C) to 250°F (120°C)
Plated Steel
